0.3mm ASTM A312 Seamless 316Ti Stainless Steel Pipe

Certification
China Shanghai Haosteel Co., Limited certification
China Shanghai Haosteel Co., Limited certification
Good quality, fast delivery, Haosteel has been supplying heat exchanger tubes for many years , we really appreciate your support!

—— Massimiliano Rossi

Haosteel is really a professional supplier, they always give us technical advice and provide good quality tubes with very competitive price!

—— Thomas Hoover

I'm Online Chat Now

0.3mm ASTM A312 Seamless 316Ti Stainless Steel Pipe

0.3mm ASTM A312 Seamless 316Ti Stainless Steel Pipe
0.3mm ASTM A312 Seamless 316Ti Stainless Steel Pipe 0.3mm ASTM A312 Seamless 316Ti Stainless Steel Pipe 0.3mm ASTM A312 Seamless 316Ti Stainless Steel Pipe

Large Image :  0.3mm ASTM A312 Seamless 316Ti Stainless Steel Pipe

Product Details:
Place of Origin: CHINA
Brand Name: HAOSTEEL
Certification: ISO9001 SGS
Model Number: HSRT304 304L 316 316L 316Ti 321 310S 2205 2507
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Woven bags and plastic strips inside packing, wooden / iron pallet and steel strips outside packing.
Delivery Time: 5-10 working days after order confirmed and receive deposit
Supply Ability: 5000tons per month
Detailed Product Description
Product: 316 316L 316Ti 310S 321 Stainless Steel Coil Tubing Standard: ASTM A312, ASTM A213, ASTM A249, ASTM A554
Grade: 201 304 304L 316 316L 321 310S 430 2205 Surface: Mill Or Bright
Technique: Cold Drawn Hot Roll Shape: Round Square Pipe
Type: Welded, Seamless Thickness: 0.3mm ~ 20mm
OD: 6mm ~800mm Length: Max 3500M
High Light:

316Ti Stainless Steel Pipe

,

Seamless Stainless Steel Pipe

,

ASTM A312 Stainless Steel Pipe

316 316L 316Ti 310S 321 304 321 Stainless steel tubing pipe



HAOSTEEL is one of the most professional manufacturer and supplier of stainless steel Tube.Stainless steel tube can be divided into seamless tube and welded tube according to production mode. Seamless tube can be divided into hot rolled tube, cold rolled tube, cold drawn pipe and extruded tube.The welded pipe is divided into straight welded pipe and spiral welded tube.

Description:

Haosteel have a large range of ASTM A249 304 304L 316 316L 316Ti 310S 321 317L 410 420 430 2205 2507 904L Stainless Steel Coil Pipe We offers a wide range of Round Pipes & Tubes, Coil, ‘U’ Shape tubes, Square pipes & tubes, Rectangular tubes, Seamless Pipe for the Chemical IndustryStainless Steel Pipes, TubesSeamless Steel Pipe for Boilers Capillary Pipes and Tubes



Grade: 201 304 304L 316 316L 316Ti 321 310S 317L 2205 2507 410 420 430 904L 625 825 ec t

Test : Yield strength, Tensile strength, Hardness ,Hydrapress Measurement

Guarantee&Inspection : The Third Party &Cetification ISO SGS

Advantage: We are a manufacturer . Lowest Price and Good Quantity

Composition Specification (%)

UNS

Grade

ASTM

Grade

Chemical Composition/%
C Mn P S Si Cr Ni Mo Re
S31653 316LN ≤0.03 ≤2.00 ≤0.45 ≤0.030 ≤2.00

16.0-18.0

10.0-14.0

2.0-3.0

N:

0.10-0.16

S31609 316H

0.04-0.1

≤2.00 ≤0.45 ≤0.030 ≤2.00

16.0-18.0

10.0-14.0

2.0-3.0


S31668 316Ti ≤0.08 ≤2.00 ≤0.045 ≤0.030 ≤2.00

16.0-18.0

10.0-14.0

2.0-3.0

Ti: ≥5C
S31651 316N ≤0.08 ≤2.00 ≤0.045 ≤0.030 ≤2.00

16.0-18.0

10.0-14.0

2.0-3.0

N:

0.10-0.16

Mechanical Property Specification

Grade

Tensile Strength

(MPa)

min

Yield Strength 0.2% Proof

(MPa)min

Elongation

(% in 50mm)

min

Hardness

Rockwell B

(HRB)max

Brinell

(HB)max

316 515 205 40 95 217
316L 485 170 40 95 217
316H 515 205 40 95 217
316Ti 515 205 40 95 217
316H also has a requirement for a grain size of ASTM No 7 or coarser.

Physical Properties (typical values in the annealed condition)

Grade Density (kg/m3)

Elastic Modulus

(GPa)

Mean Coefficient of Thermal Expansion Thermal Conductivity

Specific Heat

0-100°C

( J/kg.K)

Electrical Resistivity

(nW.m)

0-100°C

(mm/m/°C)

0-315°C

(mm/m/°C)

0-538°C

(mm/m/°C)

at 100°C (W/m.K) at 500°C (W/m.K)

316 &

316L/H/Ti

8000 193 15.9 16.2 17.5 16.3 21.5 500 740
