1.4404 Low Carbon Steel Plate EN 10088-2 Standard 1D No.1 Surface 5 Feet Width

Negotiation
MOQ
Negotiation
Price
1.4404 Low Carbon Steel Plate EN 10088-2 Standard 1D No.1 Surface 5 Feet Width
Features Gallery Product Description Request A Quote
Features
Specifications
Product: Stainless Steel Plate
Standard: EN 10088-2: 2014
Grade: 1.4404 1.4401 1.4571 1.4541 1.4462 1.4845
Surface: 1D 1U 1C 1E No.1
Solution: 1030-1150℃ Water Or Air Cooling
Thickness: 3~200mm
Width: Max 3m
Length: Max 15m
High Light:

stainless steel metal plate

,

steel sheet plate

Basic Infomation
Place of Origin: China
Brand Name: TISCO BAOSTEEL HAOSTEEL
Certification: SGS, BV, CCIC
Model Number: HS1.4404
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 5-10 Woking Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20000 Tons per Month
Product Description

1.4404 Stainless Steel Plate EN 10088-2 standard 1D No.1 surface 5 feet width



Company Brief Introduction:

HAOSTEEL is one of the most professional manufactuer and supplier of stainless steel plate. Comapny culture: person oriented and customer centered. In the past 30 year, HAOSTEEL make good business relationship with more than 40 countries and regions, aiming to be the world’s most value partner.



Material Brief Introduction:

1.4404 is a low carbon austenitic chromium-nickel stainless steel with corrosion resistance similar to type 1.4401 but with resistance to intergranular corrosion following welding.
1.4404 can be cold rolled to achieve the temper properties required by specific customers and / or manufacturing requirements. For tempers 1/2 hard or above consult Haosteel Technical Services for more information.

1.4404 Stainless Steel (Alloy 316/316L) is molybdenum-bearing austenitic stainless steel. The higher nickel and molybdenum content in this grade allows it to demonstrate better overall corrosion resistant properties than 304, especially with regard to pitting and crevice corrosion in chloride environments. In addition, Alloy 316/ 316L provides excellent elevated temperature tensile, creep and stress-rupture strengths, as well as outstanding formability and weldability. 316L is the lower carbon version of 316 and is immune from sensitization; therefore, it is very frequently used in heavy gauge welded components.

EN 10088-2 include stainless steel plate, stainless steel sheet, stainless steel coil, stainless steel strip.

1. Stainless steel plate is hot rolled thick type, thickness is ≥3mm, supply range is 3~200mm.

2. Stainless steel sheet is cold rolled thin type, thickness is ≤6mm. supply range is 0.01~6mm.

3. Stainless steel coil include both hot rolled and cold rolled, width is ≥600mm, supply range 0.6~2.0m.

4. Stainless steel strip include both hot rolled and cold rolled, width is <600mm, supply range 3~600mm.



Material Specification:

Sr.No Standard Specification Material Grade
1 EN 10088-2: 2014 1.4401
2 ASTM A240 / A240M - 14 S31608 , 316
3 JIS G 4304: 2012 SUS316



Chemical Composition:

Sr.No Grade C Mn P S Si Cr Ni Mo N
1 1.4404 0.03 2.00 0.045 0.030 1.00 16.5-18.5 10.0-13.0 2.0-2.5 0.11
2 316L 0.03 2.00 0.045 0.030 0.75 16.0-18.0 10.0-14.0 2.0-3.0 0.10
3 SUS316L 0.03 2.00 0.045 0.030 0.75 16.0-18.0 12.0-15.0 2.0-3.0 -



Mechanical properties:

Grade Tensile Strength Yield Strength Elongation Hardness, Max
MPa, min Mpa, min %, min HB HRB HV
1.4401 520-670 210 45 - - -
316 515 205 40 201 92 -
SUS316 520 205 40 187 90 200



Finishes
#1–Hot rolled annealed and descaled. It is available in strip, foil and ribbon. It is used for applications where a smooth decorative finish is not required.
#2D–Dull finish produced by cold rolling, annealing and descaling. Used for deep drawn parts and those parts that need to retain lubricants in the forming process.
#2B–Smooth finish produced by cold rolling, annealing and descaling. A light cold rolling pass is added after anneal with polished rolls giving it a brighter finish than 2D.
#BA-Bright annealed cold rolled and bright annealed
Polished-Various grit finish for specific polish finished requirements.
*Not all finishes are available in all alloys – Contact Haosteel Sales for more information



Application:

Food preparation equipment, especially in chloride environments

Chemical processing, equipment

Laboratory benches and equipment

Rubber, plastics, pulp & paper machinery

Pollution control equipment

Boat fittings, value and pump trim

Heat exchangers

Pharmaceutical and textile industries

Condensers, evaporators and tanks



Export Packing:

1. Unit weight: 2-3tons per package or as client request.

2. Packing Type: strong wooden pallet and steel strip reinforcement, or as clients' request.1.4404 Low Carbon Steel Plate EN 10088-2 Standard 1D No.1 Surface 5 Feet Width 0
