Payment & Shipping Terms:
|Product:||China Manufacturer Carbon Steel For Oil And Water Large Diameter Pipe Price Low Carbon Steel||Standard:||ASTM, BS, DIN, GB, JIS|
|Grade:||10#-45#, 16Mn, API J55-API P110, Q195-Q345, 10#, 20#, 16Mn, API J55, API K55, API L80, Q195, Q235, Q345||Thickness:||0.5 - 20 Mm|
|Outer Diameter:||20 - 610 Mm||Technique:||Cold Rolled|
|Application:||Structure Pipe, Fluid Pipe||Surface:||Galvanized Coated, Bare， Oil， Paint， Varnish|
|Length:||1-12m||Keyword:||Cold Rolled Carbon Pipe|
China Manufacturer carbon steel for oil and water large diameter pipe price low carbon steel
Carbon steel pipe can be divided into seamless steel pipe, straight steel pipe, spiral steel pipe, high frequency welded steel pipe and so on.Carbon steel seamless steel pipe is a kind of long steel.
The pipe has a hollow section and is used in a large number of pipelines for fluid transportation, such as those for oil, natural gas, gas, water and some solid materials.
Generally, the outer diameter of hot-rolled seamless pipe is greater than 32mm, the wall thickness is 2.5-75mm, the outer diameter of cold-rolled seamless pipe can be up to 6mm, the wall thickness can be up to 0.25mm, and the outer diameter of thin-walled pipe can be up to 5mm, the wall thickness is less than 0.25mm, and the precision of cold rolling is higher than that of hot rolling.
General carbon steel pipe: it is made of 16Mn, 5MnV and other low-alloy structural steels, such as 10, 20, 30, 35, 45, 45 etc.Seamless pipes made of mild steel such as 10 and 20 are mainly used for fluid transportation pipes.The seamless pipe made of medium carbon steel such as 45 and 40Cr is used to make mechanical parts, such as mechanical parts of cars and tractors.Carbon steel tubes are generally used for strength and flattening tests.The hot-rolled steel pipe is delivered in the hot-rolled or heat-treated condition;Cold rolling is delivered as heat treatment.
|Property||China Manufacturer carbon steel for oil and water large diameter pipe price low carbon steel|
|Technique||Hot rolling; cold drawing; NDT test; UT test; Hydrostatic Tester|
|usage||Used for low pressure liquid delivery, such as water, gas, and oil; construction and piling|
|standard||API 5L, API 5CT, ASTM A106/A53, ASTM A519, JIS G 3441, JIS G3444,
JIS G3445 DIN 2391, EN10305, EN10210, ASME SA106, SA192, SA210, SA213, SA335, DIN17175, ASTM A179…
|Certification||API 5L PSL1 / PSL2, API 5CT, ISO 9001-2008|
|Grade||API 5L :API 5L: GR B, X42, X46, X56, X60, X65, X70
ASTM A53/A106: GR A, GR B, GR CASME SA106: GR.A, GR.B, GR.CASME
SA192ASME SA209M: T1, T1a
ASTM A335:P1, P2, P5, P9, P11, P22, P23
ASTM A333:Gr.1, Gr.3, Gr.4, Gr.6, Gr.7, Gr.8, Gr.9, Gr.10, Gr.11
|Out diameter||10.3mm– 762mm|
|Length||Random Length, Fixed Length, SRL, DRL|
|End||Beveled end,plain end meet your need|
|Surface tratment||Black painting,bare pipe,Oiled,Hot dip galvanized|
|Package||1. big diameter: in loose|
|2. small diameter:packaged in bundles with strips|
|3. as per clients' requirement|
|Delivery time||20days after receive deposite|
1. Fluid pipe
2. Power Plant
3. Structure pipe
4. High and low pressure Boiler tube
5. Seamless pipe /tube for petroleum cracking
6. Conduit pipe
7. Scaffolding pipe pharmaceutical andship,building etc.
Rolling seamless carbon steel pipe is divided into hot rolling and cold rolling (drawing) pipe.
Hot rolled carbon steel pipe is divided into general steel pipe, low and medium pressure boiler pipe, high pressure boiler pipe, alloy pipe, stainless steel pipe, petroleum cracking pipe, geological pipe and other steel pipe, etc.
Cold rolled (dial) carbon steel pipes include general steel pipe, low-medium pressure boiler steel pipe, high-pressure boiler steel pipe, alloy steel pipe, stainless steel pipe, petroleum cracking pipe, and other steel pipe, including carbon thin-walled steel pipe, alloy thin-walled steel pipe, stainless steel pipe, and special-shaped steel pipe.
Oil pipe mainly used for transport oil and gas,and also widely used as transmission fluid pipe,
such as transport oil, natural gas, coal gas, water and some solid pipeline etc.
