SUS304 Hot Rolled Steel Plate / SS 304 310 316 420 Sheet Metal Plate

China SUS304 Hot Rolled Steel Plate / SS 304 310 316 420 Sheet Metal Plate supplier
SUS304 Hot Rolled Steel Plate / SS 304 310 316 420 Sheet Metal Plate supplier SUS304 Hot Rolled Steel Plate / SS 304 310 316 420 Sheet Metal Plate supplier SUS304 Hot Rolled Steel Plate / SS 304 310 316 420 Sheet Metal Plate supplier SUS304 Hot Rolled Steel Plate / SS 304 310 316 420 Sheet Metal Plate supplier

Large Image :  SUS304 Hot Rolled Steel Plate / SS 304 310 316 420 Sheet Metal Plate

Product Details:

Place of Origin: China
Brand Name: TISCO BAOSTEEL HAOSTEEL
Certification: SGS, BV, CCIC
Model Number: SUS304

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Standard Export Packing
Delivery Time: 5-10 Woking Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20000 Tons per Month
Contact Now
Detailed Product Description
Product: Stainless Steel Plate Standard: ASTM, AISI, DIN, JIS
Grade: 201/304/304L/321/316/316L/309/309S/310S/904L Delivery: Hot Rolled, Annealed And Pickled
Surface: BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D Thickness: 3~200mm
Width: Max 2.5m Length: Max 15m Request

JIG G4304 SUS304 stainless steel plate hot rolled pickled solution annealing 1500x3000mm

Company Brief Introduction:

HAOSTEEL is one of the most professional manufactuer and supplier of stainless steel plate. Comapny culture: person oriented and customer centered. In the past 30 year, HAOSTEEL make good business relationship with more than 40 countries and regions, aiming to be the world’s most value partner.

Material Brief Introduction:

SUS304 is an universal stainless steel that is widely used to make equipment and parts which require good overall performance (corrosion resistance and formability). In order to maintain the corrosion resistance inherent in stainless steel, the steel must contain more than 18% chromium and more than 8% nickel.

SUS304 stainless steel plate has good corrosion resistance, heat resistance, low temperature strength and mechanical properties, good hot workability such as stamping and bending, no heat treatment hardening, and no magnetism. In addition to SUS304, other commonly used materials SUS304L, SUS316, SUS316L, SUS316Ti, SUS321, SUS310S, SUS347H, etc.

JIS G 4304 include stainless steel plate, stainless steel sheet, stainless steel coil, stainless steel strip.

1. Stainless steel plate is hot rolled thick type, thickness is ≥3mm, supply range is 3~200mm.

2. Stainless steel sheet is cold rolled thin type, thickness is ≤6mm. supply range is 0.01~6mm.

3. Stainless steel coil include both hot rolled and cold rolled, width is ≥600mm, supply range 0.6~2.0m.

4. Stainless steel strip include both hot rolled and cold rolled, width is <600mm, supply range 3~600mm.

Material Specification:

Sr.No Standard Specification Material Grade
1 JIS G 4304: 2012 SUS304
2 ASTM A240 / A240M - 14 S30400 , 304
3 EN 10088-2: 2014 1.4301

Chemical Composition:

Sr.No Grade C Mn P S Si Cr Ni N
1 SUS304 0.08 2.00 0.045 0.030 0.75 18.0-20.0 8.0-10.5 -
2 304 0.08 2.00 0.045 0.030 0.75 18.0-20.0 8.0-10.5 0.10
3 1.4301 0.07 2.00 0.045 0.030 1.00 17.5-19.5 8.0-10.0 0.11

Mechanical properties:

Grade Unit Tensile Strength Yield Strength Elongation Hardness, Max
MPa, min Mpa, min %, min HB HRB HV
SUS304 520 205 40 187 90 200
304 515 205 40 201 92 -
1.4301 520-720 210 45 - - -

Application:

1. Tools, cutting tools, tableware, stamping products.
2. Mechanical manufacturing, solid parts, structural parts, shafts, bearings.
3. Construction, heavy oil burner parts, household appliance parts.
4. Petroleum and petrochemical, power industry, pressure vessels, boilers.
4. Transportation, tank trucks, metal products, machinery manufacturing.
5. Decoration, welded pipe, automobile exhaust pipe, modified rolling, cold rolled plate.

Export Packing:

1. Unit weight: 2-3tons per package or as client request.

2. Packing Type: strong wooden pallet and steel strip reinforcement, or as clients' request.SUS304 Hot Rolled Steel Plate / SS 304 310 316 420 Sheet Metal Plate

SUS304 Hot Rolled Steel Plate / SS 304 310 316 420 Sheet Metal Plate
