Product Details:
Payment & Shipping Terms:
|
| Grade: | 200 Series，300 Series，400 Series 600 Series | Standard: | AISI, JIS |
|---|---|---|---|
| Length: | 300-6000mm | Thickness: | 0.03-3mm |
| Width: | 600-1550mm | Model Number: | 304 Stainless Steel Sheet |
| Type: | Sheet Plate | Surface: | 2B,BA,No.4, Mirror 8K. |
| High Light: | ss 304 sheet,ss steel sheet |
||
ASTM A240 is Standard Specification for Chromium and Chromium-Nickel Stainless Steel Plate, Sheet, and Strip for Pressure Vessels and for General Applications
Standard: ASTM A240
Product grade: industrial grade/hot rolling, food grade/cold rolling
Product surface: 2B, 1D, N0.1, etc., can do polishing, drawing, 8K mirror, oil grinding and other surface processing
Grade: 301 , 304 , 304L , 316 , 316L , 316Ti , 321 , 310S , 2205 , 2507 , 410 , 420 , 430
Delivery Condition: Cold Rolled or Hot Rolled.
Available Dimension:
Dimension for Coil: Thickness: 0.03 mm - 3 mm Width: 1000 mm, 1219 mm, 1500 mm
Dimension for Plate/Sheet: Thickness: 0.3 mm - 3mm Width: 1000 mm, 1219 mm, 1500 mm
Length: 2000 mm, 2438 mm, 3000 mm, 3048 mm, 6000 mm
Chemical Composition of ASTM A240 Hot Rolled and Cold Rolled Stainless Steel Plate:
| UNS Designation | Type | C | Mn | P | S | Si | Cr | Ni | Mo | N | Other Elements |
| S30100 | 301 | 0.15 | 2.00 | 0.045 | 0.030 | 1.00 | 16.0-18.0 | 6.0-8.0 | 0.10 | ||
| S30400 | 304 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 17.5-19.5 | 8.0-10.5 | 0.10 | ||
| S30403 | 304L | 0.03 | 2.00 | 0.045 | 0.030 | 0.75 | 17.5-19.5 | 8.0-12.0 | 0.10 | ||
| S31600 | 316 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | 0.10 | |
| S31603 | 316L | 0.03 | 2.00 | 0.045 | 0.030 | 0.75 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | 0.10 | |
| S31635 | 316Ti | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | 0.10 |
Ti 5 x(C + N) |
| S32100 | 321 | 0.08 | 2.00 | 0.045 | 0.030 | 0.75 | 17.0-19.0 | 9.0-12.0 | 0.10 |
Ti 5 x(C + N) |
Mechanical Property of ASTM A240 Hot Rolled and Cold Rolled Stainless Steel Plate:
|
UNS Designation |
Type | Tensile Strength | Yield Strength | Elongation in 2 in. or 50 mm,min, % |
Hardness, max | |||
| ksi | Mpa | Ksi | Mpa | Brinell | Rockwell B | |||
| S30100 | 301 | 75 | 515 | 30 | 205 | 40 | 217 | 95 |
| S30400 | 304 | 75 | 515 | 30 | 205 | 40 | 201 | 92 |
| S30403 | 304L | 70 | 485 | 25 | 170 | 40 | 201 | 92 |
| S31600 | 316 | 75 | 515 | 30 | 205 | 40 | 217 | 95 |
| S31603 | 316L | 70 | 485 | 25 | 170 | 40 | 217 | 95 |
| S31635 | 316Ti | 75 | 515 | 30 | 205 | 40 | 217 | 95 |
| S32100 | 321 | 75 | 515 | 30 | 205 | 40 | 217 | 95 |
ASTM A240 grade 301 304 304L 316 316L 321 stainless steel plate is used for Pipe and Tube raw materials, Pressure Vessels, Food and Beverage, Water Treatment, Storage Tanks, Acid Process Equipment, Kitchenware, Mechinary, metalwire, Petrochemical, decoration, Structural Parts, Structural Conveyors, etc.
Application: kitchen equipment, food machinery, elevator decoration, construction engineering, environmental protection equipment, chemical equipment, shipbuilding, pharmaceutical equipment and other industries or fields.
Haosteel is one of the leading China Steel Plate/Coil manufacturers and suppliers, if you want to buy or import best high-quality astm a240 stainless steel plate/coil professional company, factory, seller, and exporter, or if you are checking steel brands, please feel free to contact us.
Hot Tags: ASTM A240 steel plate ASTM A240 steel sheet ASTM A240 301 steel ASTM A240 304 steel ASTM A240 316 steel ASTM A240 321 steel
