Immersion Boiler Electric Flange Tubular Heating Element
Product Overview:
It is an international popular high quality and long life electric heating equipment. Used for heating, heat preservation and heating of flowing liquid and gaseous medium. When the heating medium under pressure through the heating chamber of the electric heater, using the principle of fluid thermodynamics to evenly take away the huge heat generated by the work of the electric heating element, so that the temperature of the heated medium to meet the requirements of the user process.
Product working principle:
Explosion-proof electric heater is a kind of energy consumption into heat energy, to heat the material to be heated. Work in cryogenic fluid through the pipe under the action of pressure into the input port, along the electric heating container within specific in hot runner, the path of the design with the principle of fluid thermodynamics, take away the heat energy produced by electric heating element work, make the heating medium temperature, electric heater export process requirements of the high temperature medium. The internal control system of the electric heater automatically adjusts the output power of the electric heater according to the temperature sensor signal of the output port, so that the medium temperature of the output port is uniform; When heating element overtemperature, heating element independent overheating protection device immediately cut off the heating power, avoid heating material overtemperature caused by coking, metamorphism, carbonization, serious heating element burn out, effectively prolong the service life of the electric heater.
Application scope:
Typical applications of explosion-proof electric heaters are:
1, chemical industry of chemical materials heating, some powder drying under a certain pressure, chemical process and spray drying.
2, hydrocarbon heating, including petroleum crude oil, heavy oil, fuel oil, heat conduction oil, lubricating oil, stone wax, etc
3, process water, superheated steam, molten salt, nitrogen (air) gas, water gas and other fluid heating heating.
4, due to the use of advanced explosion-proof structure, the equipment can be widely used in chemical industry, military industry, oil, natural gas, offshore platforms, ships, mining areas and other explosion-proof sites.
flange heating pipe | |||
Wattage | Length | Wattage | Length |
2kw | 230mm | 12kw | 500mm |
3kw | 230mm | 15kw | 580mm |
6kw | 340mm | 18kw | 660mm |
9kw | 420mm | customized |
Advantages
1. The surface power is large, which is 2~4 times of the surface load of air heating.
2. Highly intensive and compact structure. Because the whole is short and dense, it has good stability
and no support is needed for installation.
3:For the first installation, it is recommended to buy it together with the Female Flange
Explosion-proof flange heating pipe | |||
Watt | Size | Watt | Size |
10kw | Φ108*1000mm | 100kw-120kw | Φ325*1500mm |
20kw | Φ133*1200mm | 140kw-160kw | Φ325*1800mm |
30kw | Φ159*1200mm | 180-200kw | Φ377*2000mm |
40-50kw | Φ219*1400mm | 240-270kw | Φ377*2500mm |
60kw | Φ219*1500mm | 300-360kw,400-450kw | Φ426*2500mm |
70-90kw | Φ273*1500mm | customized |
